HYDRAULIC MOTOR MR 50
Article code:
11248
OEM:
9990000016952
Tax rate
22 %
Price without VAT:
163,93 EUR
Price with VAT:
200,00 EUR
Ref:
4
| Technical data | |
| Supplier: | Bulgaria |
| Return or exchange: | 14 days |
| Warranty: | 6 months |
| Shaft diameter: | 25 mm |
| Oil flow: | constant flow 40 L/min, intermittent 50 L/min |
| Connection thread: | 1/2" |
| Temperature range: | from -40°C to 140 °C |
| Torque: | constant torque 10 daNm, intermittent 13 daNm, max. 17 daNm |
| Revolutions: | constant revolutions 775 rpm, intermittent 970 rpm |
| Pressure drop: | constant pressure 140 bar, intermittent 175 bar, max. 225 bar |
| Inlet pressure: | constant pressure 175 bar, intermittent 200 bar, max. 225 bar |
| Power: | constant power 7 kW, intermittent 8,5 kW |
| cm³/revolution: | 51,5 |
| Weight: | 6,9 kg |
DESCRIPTION – HYDRAULIC MOTORS MR
MR type hydraulic motors are compact, robust and reliable with orbital design. Due to their simple construction and high efficiency, they are suitable for a wide range of applications.
They are characterized by:
- high displacement at low speeds,
- smooth and quiet operation,
- long service life thanks to high-quality materials and seals,
- possibility of operation in both directions of rotation,
- low oil consumption relative to output power.
They are mainly used in agricultural, forestry and construction machinery, as well as in industry where reliable and efficient conversion of hydraulic energy into mechanical motion is required.
| L | L1 | |
| (mm) | (mm) | |
| MR 50 | 135,5 | 6,67 |
| MR 80 | 139,5 | 10,67 |
| MR 100 | 142 | 13,33 |
| MR 125 | 145,5 | 16,67 |
| MR 160 | 150 | 21,33 |
| MR 200 | 155,5 | 26,67 |
| MR 250 | 162 | 33,33 |
| MR 315 | 171,5 | 42,67 |
| MR 400 | 182 | 53,33 |
